Cathode IST137762 #8

Closed
opened 5 years ago by jebba · 3 comments
jebba commented 5 years ago
Owner

ProtoExpress IST137762:

"For the DFA checks, we need you to advise if the marked pad of components mentioned below is cathode:
D10 D13 D14 D16 D17 D23 D24 D25 D26 D27 D29 (LINE ITEM#10) [MPN: 1N4148WS]
D20 D21 (LINE ITEM#11) [MPN: BZT52C3V6S-7-F]
D12 D15 (LINE ITEM#12) [MPN: NSR0530HT1G]
D3 D7 D22 (LINE ITEM#13) [MPN: LTST-C170TBKT]
D2 D6 D18 (LINE ITEM#15) [MPN: LTST-C170TGKT]
D1 D5 (LINE ITEM#17) [MPN: LTST-C170KFKT]
D0 D4 D11 D19 (LINE ITEM#18) [MPN: LTST-C170KRKT]"

ProtoExpress IST137762: "For the DFA checks, we need you to advise if the marked pad of components mentioned below is cathode: D10 D13 D14 D16 D17 D23 D24 D25 D26 D27 D29 (LINE ITEM#10) [MPN: 1N4148WS] D20 D21 (LINE ITEM#11) [MPN: BZT52C3V6S-7-F] D12 D15 (LINE ITEM#12) [MPN: NSR0530HT1G] D3 D7 D22 (LINE ITEM#13) [MPN: LTST-C170TBKT] D2 D6 D18 (LINE ITEM#15) [MPN: LTST-C170TGKT] D1 D5 (LINE ITEM#17) [MPN: LTST-C170KFKT] D0 D4 D11 D19 (LINE ITEM#18) [MPN: LTST-C170KRKT]"
27 KiB
44 KiB
38 KiB
38 KiB
88 KiB
jebba commented 5 years ago
Poster
Owner
There is no content yet.
53 KiB
66 KiB
jebba added the Manufacturing label 5 years ago
ivan_o was assigned by jebba 5 years ago
ivan_o commented 5 years ago
Collaborator

Yes, marked pads are cathodes

Yes, marked pads are cathodes
jebba commented 5 years ago
Poster
Owner

Sent to ProtoExpress.

Sent to ProtoExpress.
jebba changed title from Cathode to Cathode IST137762 5 years ago
jebba closed this issue 5 years ago
